Chain Stitch Industrial Quilting Machine Multi Needle High Speed 800r / Min
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | YuTeng |
Payment & Shipping Terms:
| Price: | $35,000.00/sets 1-1 sets |
|---|---|
| Packaging Details: | The wooden case |
|
Detail Information |
|||
| Applicable Industries: | Other, Mattress Factory | Showroom Location: | None |
|---|---|---|---|
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | Ordinary Product | Warranty Of Core Components: | 1 Year |
| Core Components: | Motor | Condition: | New |
| Max Sewing Speed: | 30-200(m/hour) | Max Sewing Thickness: | 25mm |
| Number Of Head: | 2 | Moving Style: | Frame Moved |
| Voltage: | 380V/220v 50h | Power: | 3.5KW |
| Dimension(L*W*H): | 3950*1400*1800 | Weight: | 3200 |
| Warranty: | 1 Year | Product Name: | Quilting Machine Prices |
| Highlight: | Chain Stitch Industrial Quilting Machine,Industrial Quilting Machine Multi Needle,800r/Min chain stitch quilting machine |
||
Product Description
High Speed Computerized Chain Stitch Multi Needle Quilting Machine
Our Advantages
Computerized speed governing , max.800r/min.
Needle row driven by aluminum alloy needle bar frame structure. Oil free, sturdy and durable.
Saddles and Rollers driven by Servo drive equipment, Spindle adopts frequency conversion control.
Saddles using quilting machine with high rigidity design. The stand of fabric separate from saddles, effectively reduce the
operating load of motor.
Dual clutch device, to solve the synchronization problem of rollers in front and back.
Using high-precision and high rigidity Imported screw mandrel.
360 degree free quilting come with unlimited Multi-span quilting independent patterns.
Automatic thread-break detection unit.
Infrared sensor make sure more safety operation.
The machine runs smoothly, low noise, high precision, low thread-break rate and easy to operate.
Needle row driven by aluminum alloy needle bar frame structure. Oil free, sturdy and durable.
Saddles and Rollers driven by Servo drive equipment, Spindle adopts frequency conversion control.
Saddles using quilting machine with high rigidity design. The stand of fabric separate from saddles, effectively reduce the
operating load of motor.
Dual clutch device, to solve the synchronization problem of rollers in front and back.
Using high-precision and high rigidity Imported screw mandrel.
360 degree free quilting come with unlimited Multi-span quilting independent patterns.
Automatic thread-break detection unit.
Infrared sensor make sure more safety operation.
The machine runs smoothly, low noise, high precision, low thread-break rate and easy to operate.
Product Paramenters
| Model | YGH64,YGH80Y,YGH96 |
| Dimension(L×W×H)(mm) | 3950*1400*1800,4250*1400*1800,4900*1400*1800 |
| Quilting width | 1650mm,2000mm,2450mm |
| Needle rows | 2/3 |
| Space between needle rows | 3"/3"+1.5"/3"+2"/3"+3" |
| Space between needle | 25.4mm |
| X-axis movement displacement | 203.2mm,170mm,254mm |
| Thickness of quilting | ≤25mm |
| Stitch length | 1-12mm |
| Speed of operation | 30-200(m/hour) |
| Model spindle machine | 7#,10# |
| Model of needle | 16#,19# |
| Quilting speed | 850(r/min) |
| Voltage(AC) | 380V/220V/50HZ |
| Total power | 3.5KW,5.5KW |
| Gross weight | 3200KG,3650KG,4250KG |
Product Show
Finished Product Display
Company Profile
Company Profile
DongGuan YuTeng Machinery Technology Co., Ltd. Is a modernized, high-tech enterprise specializing in High-speed Computerized Shuttle (Lock Stitch) Multi-Needle Quilting Machine, Double Rows Computerized Quilting and Embroidery Machine ,Computerized Chain Stitch Multi-Needle Quilting Machine ,Computerized Panel Cutter Machine, Rolling machine .The products are widely used in garment, bedding, handbags and household ornament etc. With strong R&D both in machinery and software, our company focuses on the the profound development in production, sales, and Service. The founder of YuTeng Machinery, Mr Xiaoke Hu, who engaged in quilting machinery Industry for over. 20 years, proficient in advanced manufacturing technology, unique designs and Innovation. He has won a good reputation in the Industry. With Innovative technology, stable quality and high quality after service, products in his brand sell very good at home and abroad . Leading an outstanding R&D team more than 20 professional engineering and technical personnel and customer service outlets throughout the country, YeTeng always provides clients with full technical support and perfect after service. With integrity, profession, innovation, science and technology, YuTeng is looking forward to cooperating with companies from all over the world.
